ZB4-BG1
ActiveHarmony XB4 2-Position Key Switch
Series picture: the seller uses it for 21 other parts too, so it may not show this exact version.
2-position key-operated selector switch head for Schneider Harmony XB4 series. 22mm cutout, IP66. Key removable in both positions.
Common Applications
Key-operated selector switch used to restrict access to specific machine modes — only personnel with the key can switch between positions. Common on pharmaceutical filling lines (locking out manual mode during production), food processing equipment (preventing unauthorized recipe changes), and building HVAC panels (restricting access to maintenance mode). The maintained 2-position action stays in the selected position when the key is removed from either position. Pairs with ZB4-BZ101 or ZB4-BZ102 contact blocks depending on whether the application needs NO or NC contacts.
Research Notes
1. Overview
The ZB4-BG1 (also written ZB4BG1) is a modular key-operated selector switch head from Schneider Electric's Harmony XB4 product family. It mounts in a standard 22 mm panel cutout and is designed to restrict machine mode changes to authorized personnel only — the operator must insert a physical key (Ronis key no. 455) to rotate the switch. The head is sold separately from the contact block and body; users build a complete switch by combining it with a compatible contact block such as the ZB4BZ101. The part is also marketed under the Square D brand (SQDZB4BG1) in North America.
2. User Sentiment
User and distributor feedback is broadly positive. The chromium-plated metal construction is frequently cited as a differentiator versus plastic-bezel alternatives for harsh environments. The modular design (head + contact block) is appreciated for spares flexibility — worn contact blocks can be replaced without sourcing a new key head. Pricing across distributors ranges from roughly €8 (surplus/used, German distributor) to $85–$124 USD new, which some buyers on industrial forums consider a premium but acceptable for safety-critical applications. The Ronis 455 key is a common industrial standard, making key management straightforward in multi-machine facilities. No significant negative patterns appear in available distributor and product-listing commentary.
3. Real-World Applications
The ZB4-BG1 is deployed wherever a physical key lock is required to restrict operational mode changes:
- Machine tool and CNC control panels — switching between auto, manual, and setup modes, preventing unauthorized mode changes during production.
- Automated production lines — restricting access to maintenance or bypass modes.
- Process plants and HVAC — gating transitions between local/remote or manual/automatic operation.
- Safety interlocking systems — the spring-return-from-left-to-center action with key withdrawal only in the right (center) position allows the switch to serve as a momentary authorization signal; the key cannot be removed while the switch is in an active (left) position, providing a physical interlock.
- Referenced in Schneider Electric's own Machine Expert safety documentation as a compatible operator for
SF_ModeSelectorsafety function blocks.
4. Technical Specifications
- Type: Key-operated selector switch head, 3-position, spring return
- Series: Harmony XB4 (modular 22 mm metal range)
- Mounting: 22 mm diameter panel cutout
- Key: Ronis no. 455, black, round profile
- Positions: 3 (−45° / 0° / +45°); spring return from left to center
- Key Withdrawal: Right position (center, 0°) only — key cannot be removed in left or center-active positions
- Bezel Material: Chromium-plated metal
- IP Rating: IP66 / IP67 / IP69 / IP69K (dust-tight, high-pressure washdown rated)
- Impact Rating: IK06 (with keyhole cover)
- Operating Temperature: −40 °C to +70 °C
- Mechanical Life: 1,000,000 operating cycles
- Shock Resistance: 30 gn to 50 gn (half-sine)
- Dimensions (head): 29 mm H × 29 mm W × 72 mm depth; weight 0.098 kg
- Compatible Contact Block: ZB4BZ101 (1NO, 10 A, 600 VAC, screw-clamp terminal) and other ZB4BZ-series blocks
5. Ordering & Compatibility
The ZB4-BG1 head must be combined with at least one ZB4BZ-series contact block to form a functional switch. Common pairings:
- ZB4BZ101 — 1 NO contact, 10 A, screw clamp (most common)
- ZB4BZ102 — 1 NC contact, 10 A, screw clamp
- Multiple contact blocks can be stacked on a single head.
The head fits all standard ZB4 / XB4 22 mm bodies and adapters. Compatible keys also include no. 421E, 458A, 520E, and 3131A (per Schneider datasheet), though the default shipped key is Ronis 455.
North American ordering uses the Square D prefix: SQDZB4BG1. The product complies with UL 508, CSA C22.2 No. 14, EN/IEC 60947-5-1, EN/IEC 60947-1, EN/IEC 60947-5-4, EN/IEC 60947-5-5, GB 14048.5 (China), and holds DNV-GL Marine and PSE Japan certifications, making it suitable for marine and export applications.
New pricing: approximately $85–$124 USD depending on distributor; surplus units available from €8. Lead time is typically in-stock at major distributors (RSP Supply, Automation Distribution, Kempston Controls, Border States).
6. Known Issues
No significant issues reported. One nuance worth noting: the product listing on alldatasheet.it describes it as "3-position spring return" while the TME listing states "2 stable positions" — this is consistent and not contradictory: there are 3 physical positions but only 2 stable ones (center and right); the left position is momentary (spring-return). Buyers should verify key-withdrawal position requirements match their interlock design before ordering, as other ZB4BG variants (e.g., ZB4BG2) differ in withdrawal position.
9 sources
- ZB4BG1 Scheda tecnica — Schneider Electric (Harmony XB4 key selector switch head, 3pos spring ret) — alldatasheetit.com
- Schneider Electric ZB4-BG1 Schlüsselschalter M+R rastend — ungebraucht (€8.07) — elektro-technik-grote.de
- ZB4BG1 — Head for key selector switch, Harmony XB4, black key, 22mm, 3 positions, right key withdrawal, spring return, key 455 | Schneider Electric Global — se.com
- Schneider Electric ZB4BG1 3POS SPRING RET KEY SELECTOR — rspsupply.com
- Schneider Electric ZB4BG1 Key Selector Operating Head — automationdistribution.com
- Square D / Schneider Electric Harmony ZB4 22mm Key Selector Switch Heads (ZB4BG1) — borderstates.com
- ZB4BG1 SCHNEIDER ELECTRIC — Switch: rotary with key, 22mm, 2 stable positions, black, IP66 | TME India — tme.com
- Schneider ZB4BG1 KEY SWITCH HEAD | Kempston Controls — kempstoncontrols.com
- SF_ModeSelector — Schneider Electric Machine Expert Safety Function Block — product-help.schneider-electric.com
About the Harmony XB4 range
Applies to every part of the range, not only the ZB4-BG1.
What the range is
Harmony XB4 is Schneider Electric's range of metal 22 mm pushbuttons, selector switches, key switches, emergency stops and pilot lights, with a chromium-plated (or black) metal bezel. Older parts and many shops still use the Telemecanique name. The same functions exist as 30 mm flush-mounted versions (XB4F / ZB4F), and Harmony XB5 is the plastic, double-insulated twin of the range.
How the part numbers fit together
- Complete unit = body + head. XB4BA31 is the body with its contact (ZB4BZ101) plus the head (ZB4BA3). You can also buy the three loose parts: fixing collar ZB4BZ009, contact block ZBE101 and the head.
- One letter changes the mounting: ZB4B… is the standard 22 mm head, ZB4F… the 30 mm flush version (ZB4BA3 → ZB4FA3).
- Black metal bezel: add 7 to the head (ZB4BD2 → ZB4BD27).
- Push-in terminals: complete units ending in 5 use compact push-in contact blocks (XB4BD335 instead of XB4BD33).
- Selector heads: ZB4BD2 two positions stay put; ZB4BD4 two positions, spring return from right to left; ZB4BD3 three positions stay put; ZB4BD5 spring return to centre; ZB4BD7 / ZB4BD8 spring return from left / right to centre. J instead of D is the long handle (ZB4BJ3), G a key switch, K an illuminated selector.
- Pilot lights: the letter after BV is the voltage (B = 24 V, G = 110–120 V, M = 230–240 V); the last digit is the colour.
Bodies and contact blocks
| Body with contacts | Contacts | Contact block | Type | |
|---|---|---|---|---|
| ZB4BZ101 | 1 NO | ZBE101 | NO | |
| ZB4BZ102 | 1 NC | ZBE102 | NC | |
| ZB4BZ103 | 2 NO | ZBE203 / ZBE204 / ZBE205 | double: 2 NO / 2 NC / NO + NC | |
| ZB4BZ104 | 2 NC | ZBE1016 / ZBE1026 | low-power (electronic inputs) | |
| ZB4BZ105 | 1 NO + 1 NC | ZBE201 / ZBE202 | early-make NO / late-break NC | |
| ZB4BZ141 | 1 NO + 2 NC | ZBE501–ZBE505 | high-power switching |
Contact blocks clip on in up to three rows. Illuminated units take a Universal LED light block (ZBVB1 24 V, ZBVG1 110–120 V, ZBVM1 230–240 V, marked "UN"); one block works with every lens colour.
Ratings for the whole range (Schneider catalogue, January 2026)
- IP66, IP67, IP69, IP69K and UL Type 4X; impact IK06 (the plastic XB5: IK03)
- −40 to +70 °C; up to 10 million operations for pushbuttons
- 22 mm hole, with or without the anti-rotation notch; panel 1–6 mm
- IEC, UL, CSA, CCC, EAC, JIS; marine approvals (BV, Lloyd's Register, DNV)
Individual datasheets can differ from these range figures. The XB4BD33 selector, for example, is rated for 1 million cycles.
Installing
The head holds itself in the panel hole, so one person can fit it. The body clips on from behind and is clamped with its screw (0.8 N·m, max 1.2 N·m); there is no nut, unlike the plastic XB5, whose nut is tightened with tool ZB5AZ905. Terminals take 0.34–1.5 mm² (AWG 22–16), two wires per terminal, at 0.8–1.2 N·m. Schneider says the anti-loosening terminal screws need no periodic retightening. To remove a body, put a flat screwdriver into the black tab and pull it back.
Useful accessories
- Legend holder ZBZ32 (30 × 40 mm) with printed legends such as ZBY2385 "AUTO-O-HAND", ZBY2186 "I-O-II", ZBY2178 "O-I", ZBY2303 "START", ZBY2304 "STOP"; ZBY2101 is blank for engraving
- Guards: ZBZ2102 plastic guard for selectors and key switches; ZBZ1605 metal guard for emergency stops (padlockable)
- Blanking plug ZB4SZ3 (with collar ZB4BZ009) for an unused hole; liquid-spray washer ZB4BZ007 under the head
- 30 mm flush kits ZB4BZ021 (pushbuttons, pilot lights) and ZB4BZ022 (selectors, illuminated pushbuttons)
Metal XB4 or plastic XB5?
They do the same jobs and fit the same 22 mm hole. Choose metal for impact, vibration and heat (e.g. weld spatter), plastic for double insulation and a lower price; both come in high IP versions. Schneider China notes that there XB4 is import-only while XB5 is also made locally. Schneider's cheaper ranges are Easy Harmony XA2 (metal) and XB2 / XB7.
Buying notes
- Look-alikes: many marketplace listings use XB4 codes for unbranded copies, at factory prices around $1 a piece. A seller's video comparing a "high-quality counterfeit" with a genuine contact block shows the copy's NO contact cutting out on a continuity test. Buy from an authorised distributor and check the Schneider marking.
- IP66 vs IP67/IP69K: catalogue section headers quote IP66 for whole groups of products, while the datasheets of individual parts list IP67, IP69 and IP69K. Shops copy either figure.
- Discontinued and missing codes: some complete units are no longer made, e.g. XB4BD73 (January 2022). The heads are usually still sold, so the switch can be built from head + body.
- Problems in use: we found no recurring failure pattern for the range in the forums and reviews we could read; the complaints we found were about counterfeits and wrong listings.
8 sources
- Harmony XB4 metal Control and signaling units catalog (DIA5ED2121212EN, January 2026) — Schneider Electric
- Instruction sheet XB4/XB5 - mounting and tightening torques (BRU46063) — Schneider Electric
- XB4BD73 - discontinued on 27 January 2022 — Schneider Electric
- FAQ FA421338: difference between XB4 and XB5 (2022) — Schneider Electric China
- Pulsadores Schneider Harmony XB4 y XB5 (IK06 vs IK03, ratings) — Schneider Electric Latinoamérica, YouTube, 2019
- Botonería Harmony XB4 y XB5 - how to choose — Dominio Electric, YouTube, 2024
- Mounting Tutorial: Harmony XB4/ZB4 22 mm Pushbutton & Contacts — RS Americas, YouTube, 2020
- How to Spot Counterfeit Schneider XB4 Push Buttons (seller's demo) — Alara, YouTube, 2026
Specifications
|
Actuator Type
The button head style. Flush sits level with the bezel (prevents accidental presses). Extended protrudes for easy access.
|
Key
|
|
Certifications
Third-party safety certifications. UL = required for US NEC installations. CE = EU compliance. CSA = Canadian standards.
|
UL, CSA, CE
|
|
Contact Configuration
Normally Open — circuit is off until you press. Standard for start/go/enable functions.
|
1NO (with ZB4-BZ101)
|
|
Cutout Diameter
The hole size you drill in your panel to mount this button. 22mm is the most common industrial standard worldwide.
|
22mm
|
|
IP Rating
IP66: Dust-tight and withstands powerful water jets from any direction. Standard for outdoor and washdown applications.
|
IP66
|
|
Material
The bezel/body material. Metal bezels are more durable in harsh environments. Plastic is lighter and cheaper.
|
Metal
|
|
Mounting Type
How the button attaches to the panel. Panel mount is standard — installs through a cutout from the front.
|
Panel
|
|
Max Operating Temp
Highest temperature the button is rated to operate in.
|
70°C
|
|
Min Operating Temp
Lowest temperature the button is rated to operate in.
|
-25°C
|
|
Positions
|
2
|
|
Return type
|
Maintained
|
Specs with this icon are linked to the manufacturer's original source page
You'll Also Need
This is a modular component. For a complete assembly, you may also need:
Installation Quick Reference
Panel cutout: 22mm. Align the selector positions with the desired panel markings before tightening.
Contact blocks: Attach one contact block per position. Wire each to a separate PLC input for position feedback. A 2-position switch needs 1-2 blocks; 3-position needs 2-3.
Dimensions
Wiring Diagram
Troubleshooting
Not responding to input
Check wiring continuity with a multimeter. Verify the contact block is properly seated. Inspect terminals for loose connections.
Where to Buy
Price range
$2.71 — $9.76
across 3 sellers in US dollars
Quick Specs
- Actuator Type
- Key
- Certifications
- UL, CSA, CE
- Contact Configuration
- 1NO (with ZB4-BZ101)
- Cutout Diameter
- 22mm
- IP Rating
- IP66
What People Are Saying
“Good selector for mode control applications. Make sure you get the right number of positions and maintained vs spring-return for your application.”
