Schneider Electric · Harmony XB4 Series

ZB4-BZ102

Active
UL CSA CE

Harmony XB4 1NC Contact Block

Part number: ZB4 - B - Z - 102
Schneider Electric Harmony XB4 Series Introduced circa 2003
Schneider Electric ZB4-BZ102 — Harmony XB4 1NC Contact Block

Single contact block with 1 normally closed (NC) contact for Schneider Harmony XB4 series. Screw clamp terminals.

Common Applications

Contact block with 1NC (Normally Closed) contact — the circuit is complete until the button is pressed. Used for stop buttons and emergency stops where the default safe state is "circuit closed" (fail-safe design). If the wire breaks, the circuit opens and the machine stops — same as pressing the button. Always wire NC contacts in series with the safety circuit. Can be stacked with a 1NO block on the same button for simultaneous start/stop signaling.

Research Notes

1. Overview

The ZB4-BZ102 (also written ZB4BZ102) is a normally-closed (1NC) auxiliary contact block from Schneider Electric's Harmony XB4 series, designed to mount directly onto 22mm metal pushbutton operators and selector switches. It ships with an integrated fixing/mounting collar and uses screw-clamp terminals for reliable field wiring. The block uses a slow-break, positive-opening contact mechanism that meets IEC 947-5-1 requirements for safety-critical circuits. It is part of Schneider Electric's long-running Telemecanique/Harmony modular control component family and is listed under the Square D brand (SQDZB4BZ102) in North America. The product has a two-page official datasheet (113 KB) published by Schneider Electric.


2. User Sentiment

The ZB4BZ102 earns consistently positive feedback from industrial users. SuperBreakers customers rate it 4.9 out of 5 stars across 9 reviews. Reviewers highlight its snap-on installation that requires no tools, its robust feel, and reliable long-term operation. Multiple distributors describe it as a dependable workhorse for stop and interlock circuits. No significant complaints about contact failure, compatibility problems, or premature wear appear in available sources. The product is described as straightforward to integrate into existing XB4 control stations.


3. Real-World Applications

Industrial users deploy the ZB4BZ102 in a wide range of control and safety scenarios:

  • Emergency stop and stop-button circuits — the NC contact opens upon actuation, cutting a control signal as required by safety logic.
  • PLC digital input feedback — the block provides a closed-loop signal to a controller indicating button state.
  • Motor starter auxiliary signaling — used alongside contactors and motor protection relays in panel-built control stations.
  • Safety interlocks — door, guard, and machine interlocks where a normally-closed path must be broken to prevent unsafe motion.
  • Multi-contact logic — stacked with the ZB4BZ101 (1NO) block to create start/stop or dual-contact configurations on a single operator.

The product is specifically recommended by Schneider for machine manufacturers in the automotive, textile, and timber industries, as well as for control panel integrators building machine operator stations.


4. Technical Specifications

  • Type: Single contact block, 1NC (normally closed), slow-break, positive opening
  • Series: Harmony XB4 (22mm operators)
  • Voltage Rating: 600V AC
  • Current Rating: 10A
  • Contact Material: Silver alloy
  • Terminal Type: Screw-clamp
  • Mounting: Snap-on with integrated Zamak fixing collar
  • Dimensions (H × W × D): 47mm × 30mm × 37mm (approx. 1.85" × 1.18" × 1.45")
  • Weight: ~0.053 kg (0.13 lbs)
  • Operating Temperature: −25°C to +70°C (some sources cite −40°C to +70°C)
  • IP Rating: IP65 / NEMA 4X standard; IP66 and IP69K available in the XB4 range
  • Short-Circuit Protection: 10A gG cartridge fuse per EN/IEC 60947-5-1
  • Certifications: UL, CSA, EN/IEC, NEMA, JIS, CCC, GOST, BV, DNV, LROS
  • Compliance: RoHS and REACh compliant
  • Color: Black body

5. Ordering & Compatibility

The ZB4BZ102 is widely stocked by major global distributors including Newark (17C7145), RS Components (700-07003), Superbreakers, Kent Store, Industrial Electrical Warehouse (AU), Sigma Surplus, and Standard Electric. Street pricing ranges from approximately USD $10–$29 depending on distributor and packaging (new vs. surplus). MSRP is approximately USD $22.

It is directly compatible with the Schneider Electric Harmony XB4 22mm metal operator series (ZB4B* heads). With an appropriate adapter it also fits Harmony XB5 plastic operators. The ZB4BZ101 (1NO version) and ZB4BZ102 can be stacked on a single operator for dual-contact applications. The part is also sold under the Square D catalogue prefix as SQDZB4BZ102.


6. Known Issues

No significant issues reported. The positive-opening NC contact design ensures fail-safe behavior in safety circuits. The integrated collar simplifies assembly but users should confirm XB5 adapter availability if cross-series mounting is required. Surplus/refurbished units are available from secondary market suppliers; buyers should verify condition and warranty terms when purchasing outside of authorized distribution.


13 sources
  1. ZB4BZ102 Contact Block | Reliable 1 N.C. Solution - Schneider Electric — Kent Store
  2. Schneider Electric / Telemecanique Contact Block Harmony XB4 1NC 600V ZB4-BZ102 — Industrial Electrical Warehouse (AU)
  3. Schneider Electric ZB4-BZ102 Contact Block — Sigma Surplus
  4. Schneider ZB4 BZ102 Harmony 22mm Pushbutton contact block — Bolens Control
  5. Schneider Electric ZB4BZ102 Contact Block — SuperBreakers
  6. ZB4BZ102 - Harmony, 22mm Push Button, XB4B operators, contact block, with mounting collar, 1 NC, screw clamp terminal — Schneider Electric (official)
  7. ZB4BZ102 SCHNEIDER ELECTRIC, Contact Block, Body/Fixing collar, 10 A — Newark Electronics
  8. ZB4BZ102 Schneider Electric - Switch Accessories - Distributors, Price Comparison, and Datasheets — Octopart
  9. Schneider Electric ZB4BZ102 Single Contact Block with Mounting Base 1NC Screw Terminal, ZB4 Series — RS Components (US)
  10. Product data sheet Characteristics ZB4BZ102 — RS Components / Schneider Electric (datasheet)
  11. ZB4BZ102 Datasheet(PDF) - Schneider Electric — Alldatasheet
  12. Schneider Electric ZB4BZ102 Auxiliary Contact Block 1NC for Harmony XB4 — Essential Electric Supply
  13. Schneider Electric ZB4BZ102 SQDZB4BZ102 — Standard Electric
About the Harmony XB4 range

Applies to every part of the range, not only the ZB4-BZ102.

What the range is

Harmony XB4 is Schneider Electric's range of metal 22 mm pushbuttons, selector switches, key switches, emergency stops and pilot lights, with a chromium-plated (or black) metal bezel. Older parts and many shops still use the Telemecanique name. The same functions exist as 30 mm flush-mounted versions (XB4F / ZB4F), and Harmony XB5 is the plastic, double-insulated twin of the range.

How the part numbers fit together

  • Complete unit = body + head. XB4BA31 is the body with its contact (ZB4BZ101) plus the head (ZB4BA3). You can also buy the three loose parts: fixing collar ZB4BZ009, contact block ZBE101 and the head.
  • One letter changes the mounting: ZB4B… is the standard 22 mm head, ZB4F… the 30 mm flush version (ZB4BA3 → ZB4FA3).
  • Black metal bezel: add 7 to the head (ZB4BD2 → ZB4BD27).
  • Push-in terminals: complete units ending in 5 use compact push-in contact blocks (XB4BD335 instead of XB4BD33).
  • Selector heads: ZB4BD2 two positions stay put; ZB4BD4 two positions, spring return from right to left; ZB4BD3 three positions stay put; ZB4BD5 spring return to centre; ZB4BD7 / ZB4BD8 spring return from left / right to centre. J instead of D is the long handle (ZB4BJ3), G a key switch, K an illuminated selector.
  • Pilot lights: the letter after BV is the voltage (B = 24 V, G = 110–120 V, M = 230–240 V); the last digit is the colour.

Bodies and contact blocks

Body with contactsContactsContact blockType
ZB4BZ1011 NOZBE101NO
ZB4BZ1021 NCZBE102NC
ZB4BZ1032 NOZBE203 / ZBE204 / ZBE205double: 2 NO / 2 NC / NO + NC
ZB4BZ1042 NCZBE1016 / ZBE1026low-power (electronic inputs)
ZB4BZ1051 NO + 1 NCZBE201 / ZBE202early-make NO / late-break NC
ZB4BZ1411 NO + 2 NCZBE501–ZBE505high-power switching

Contact blocks clip on in up to three rows. Illuminated units take a Universal LED light block (ZBVB1 24 V, ZBVG1 110–120 V, ZBVM1 230–240 V, marked "UN"); one block works with every lens colour.

Ratings for the whole range (Schneider catalogue, January 2026)

  • IP66, IP67, IP69, IP69K and UL Type 4X; impact IK06 (the plastic XB5: IK03)
  • −40 to +70 °C; up to 10 million operations for pushbuttons
  • 22 mm hole, with or without the anti-rotation notch; panel 1–6 mm
  • IEC, UL, CSA, CCC, EAC, JIS; marine approvals (BV, Lloyd's Register, DNV)

Individual datasheets can differ from these range figures. The XB4BD33 selector, for example, is rated for 1 million cycles.

Installing

The head holds itself in the panel hole, so one person can fit it. The body clips on from behind and is clamped with its screw (0.8 N·m, max 1.2 N·m); there is no nut, unlike the plastic XB5, whose nut is tightened with tool ZB5AZ905. Terminals take 0.34–1.5 mm² (AWG 22–16), two wires per terminal, at 0.8–1.2 N·m. Schneider says the anti-loosening terminal screws need no periodic retightening. To remove a body, put a flat screwdriver into the black tab and pull it back.

Useful accessories

  • Legend holder ZBZ32 (30 × 40 mm) with printed legends such as ZBY2385 "AUTO-O-HAND", ZBY2186 "I-O-II", ZBY2178 "O-I", ZBY2303 "START", ZBY2304 "STOP"; ZBY2101 is blank for engraving
  • Guards: ZBZ2102 plastic guard for selectors and key switches; ZBZ1605 metal guard for emergency stops (padlockable)
  • Blanking plug ZB4SZ3 (with collar ZB4BZ009) for an unused hole; liquid-spray washer ZB4BZ007 under the head
  • 30 mm flush kits ZB4BZ021 (pushbuttons, pilot lights) and ZB4BZ022 (selectors, illuminated pushbuttons)

Metal XB4 or plastic XB5?

They do the same jobs and fit the same 22 mm hole. Choose metal for impact, vibration and heat (e.g. weld spatter), plastic for double insulation and a lower price; both come in high IP versions. Schneider China notes that there XB4 is import-only while XB5 is also made locally. Schneider's cheaper ranges are Easy Harmony XA2 (metal) and XB2 / XB7.

Buying notes

  • Look-alikes: many marketplace listings use XB4 codes for unbranded copies, at factory prices around $1 a piece. A seller's video comparing a "high-quality counterfeit" with a genuine contact block shows the copy's NO contact cutting out on a continuity test. Buy from an authorised distributor and check the Schneider marking.
  • IP66 vs IP67/IP69K: catalogue section headers quote IP66 for whole groups of products, while the datasheets of individual parts list IP67, IP69 and IP69K. Shops copy either figure.
  • Discontinued and missing codes: some complete units are no longer made, e.g. XB4BD73 (January 2022). The heads are usually still sold, so the switch can be built from head + body.
  • Problems in use: we found no recurring failure pattern for the range in the forums and reviews we could read; the complaints we found were about counterfeits and wrong listings.
8 sources
  1. Harmony XB4 metal Control and signaling units catalog (DIA5ED2121212EN, January 2026) — Schneider Electric
  2. Instruction sheet XB4/XB5 - mounting and tightening torques (BRU46063) — Schneider Electric
  3. XB4BD73 - discontinued on 27 January 2022 — Schneider Electric
  4. FAQ FA421338: difference between XB4 and XB5 (2022) — Schneider Electric China
  5. Pulsadores Schneider Harmony XB4 y XB5 (IK06 vs IK03, ratings) — Schneider Electric Latinoamérica, YouTube, 2019
  6. Botonería Harmony XB4 y XB5 - how to choose — Dominio Electric, YouTube, 2024
  7. Mounting Tutorial: Harmony XB4/ZB4 22 mm Pushbutton & Contacts — RS Americas, YouTube, 2020
  8. How to Spot Counterfeit Schneider XB4 Push Buttons (seller's demo) — Alara, YouTube, 2026

Compatibility

Same compatibility as ZB4-BZ101. NC version for stop/safety circuits. Stacks with ZBE elements for 1NO+1NC on a single button.

Repair & Maintenance

Replace when button operates intermittently. Silver contacts pit over time from arcing. Check with multimeter: NC should show <1 ohm when not pressed, open when pressed. Replace the entire block — dont try to file contacts.

Specifications

Certifications
UL, CSA, CE
Contact Configuration
1NC
Current rating
10A
Terminal Type
Screw Clamp
Max Voltage
600V

Specs with this icon are linked to the manufacturer's original source page

Installation Quick Reference

Mounting: Snap onto the rear of any compatible button body in the same series. The latch clicks audibly when properly seated. Some models require a mounting adapter.

Wiring: Terminals are marked NO (11/12) or NC (21/22). Use 0.5-2.5mm² wire with ferrules. Tighten to 0.8 Nm. Verify with a multimeter before energizing.

Dimensions

Wiring Diagram

L T 21 22 NC (closed) opens on press

Troubleshooting

Intermittent switching

Silver contacts are pitted from arcing. Replace the contact block — they are consumable parts. If arcing is severe, check that the switched load doesn't exceed the contact rating (typically 6A at 120VAC).

Contact block won't snap onto button body

Verify the contact block series matches the button head series (e.g., Schneider ZB4 blocks fit ZB4 heads only, not ZB5). Check for debris or damage on the mounting tabs.

Photos & Drawings

Images: media.rs-online.com

Quick Specs

Certifications
UL, CSA, CE
Contact Configuration
1NC
Current rating
10A
Terminal Type
Screw Clamp
Max Voltage
600V

What People Are Saying

+

“Keep spares of these. Contact blocks are consumable parts — the first thing to check when a button starts acting intermittent. Cheap replacement, saves troubleshooting time.”
