Eaton · M22 Series

M22-PVT45P

Name: Eaton M22-PVT45P
Brand: Eaton
SKU: M22-PVT45P

Active

UL UL Listed — meets US safety standards. Required for NEC-inspected installations. CSA CSA Certified — meets Canadian safety standards. Required for installations in Canada. CE CE Marked — complies with EU directives (Low Voltage, Machinery, EMC). IEC 60947-5-5

M22 Emergency Stop 45mm Mushroom Twist Release

Part number: M22 22mm RMQ-Titan series - PVT45P Emergency stop, 45mm twist-release

Eaton M22 Series Introduced circa 2000

Eaton M22-PVT45P — M22 Emergency Stop 45mm Mushroom Twist Release

Red 45mm mushroom head emergency stop push button with twist-to-release reset for Eaton M22 series. 22.5mm cutout, IP67.

Common Applications

Heavy-duty emergency stop with an oversized 45mm mushroom head — 5mm larger than standard 40mm e-stops for even easier palm actuation in high-stress situations. The twist-to-release mechanism meets EN/ISO 13850 for Category 0 emergency stops. Found on large industrial presses, steel mill equipment, and heavy machinery where operators may be wearing thick gloves. The larger head also improves visibility from a distance on wide control panels. The IP67 rating suits harsh environments with coolant spray, metal dust, and vibration. Wire the 1NC contact in series with the safety relay or safety PLC input.

Specifications

Actuator Type The button head style. Flush sits level with the bezel (prevents accidental presses). Extended protrudes for easy access.	Mushroom Head
Certifications Third-party safety certifications. UL = required for US NEC installations. CE = EU compliance. CSA = Canadian standards.	UL, CSA, CE, IEC 60947-5-5
Color Button/actuator color. Green = start/go, Red = stop/emergency, Yellow = caution, Blue = reset (per IEC 60204-1).	Red
Contact Configuration Normally Closed — circuit is on until you press. Standard for stop/emergency functions. Wire in series with safety circuits.	1NC
Cutout Diameter The hole size you drill in your panel to mount this button. 22mm is the most common industrial standard worldwide.	22.5mm
Head diameter	45mm
IP Rating IP67: Dust-tight and survives temporary water submersion (1m for 30 min). Handles oil splashes, steam cleaning, and rain.	IP67
Material The bezel/body material. Metal bezels are more durable in harsh environments. Plastic is lighter and cheaper.	Plastic
Mounting Type How the button attaches to the panel. Panel mount is standard — installs through a cutout from the front.	Panel
Reset type	Twist Release

Specs with this icon are linked to the manufacturer's original source page

Compatible Alternatives

These products are functionally equivalent cross-references from other manufacturers.

Siemens

3SU1150-1HB20-1FH0

SIRIUS ACT Emergency Stop 40mm Twist Release (2NC)

IDEC

HW1B-V4F01-R

HW Emergency Stop 40mm Mushroom Twist Release

Omron

A22E-M-11B

A22E Emergency Stop 40mm Mushroom Twist Release

Installation Quick Reference

Panel cutout: 22.5mm. Mount with the yellow backing plate visible (required by EN/ISO 13850).

Wiring: Wire NC contacts in series with the safety relay input channels. Use dual-channel wiring for SIL 3 / PLe applications. Never wire directly to a motor contactor.

Testing: Press the e-stop and verify the machine stops within the required time. Test the reset mechanism. Repeat monthly per EN/ISO 13850.

Wiring Diagram

Troubleshooting

E-stop won't reset (twist/pull doesn't release)

Check for debris in the mechanism. For twist-release: turn clockwise 45-90 degrees. For push-pull: pull straight out firmly. If the mechanism is stuck, the internal latch may be damaged — replace the entire head assembly.

Machine doesn't stop when e-stop is pressed

Critical safety issue. Immediately lock out the machine. Check wiring — NC contacts must be in series with the safety relay. Verify the safety relay is functioning. A broken wire in an NC circuit should cause a stop, so check for a wiring bypass.

Safety relay faults after e-stop reset

The safety relay detects a cross-fault between the two monitoring channels. Check that both NC contacts on the e-stop are switching simultaneously. One contact may be welded closed — replace the contact block.
