A22E-M-11B
ActiveA22E Emergency Stop 40mm Mushroom Twist Release
Red 40mm mushroom head emergency stop, Omron A22E series. Twist-to-release reset, 22mm cutout, IP65, with 1NO+1NC contacts.
Common Applications
Omron emergency stop with 40mm mushroom head and twist-to-release for Category 0 emergency stopping per EN/ISO 13850. The 1NO+1NC contact configuration is useful — the NC contact feeds the safety circuit while the NO contact signals the PLC that the e-stop has been pressed, enabling diagnostic messaging on the HMI. Found on Omron-controlled packaging lines, pick-and-place robots, and semiconductor handling equipment. The A22E series is the dedicated safety device line from Omron, designed to work with Omron NX-series safety controllers. Rated IP65 for indoor industrial environments.
Specifications
|
Actuator Type
The button head style. Flush sits level with the bezel (prevents accidental presses). Extended protrudes for easy access.
|
Mushroom Head
|
|
Certifications
Third-party safety certifications. UL = required for US NEC installations. CE = EU compliance. CSA = Canadian standards.
|
UL, CSA, CE, IEC 60947-5-5
|
|
Color
Button/actuator color. Green = start/go, Red = stop/emergency, Yellow = caution, Blue = reset (per IEC 60204-1).
|
Red
|
|
Contact Configuration
1NO + 1NC: One circuit closes and one opens when pressed. Common for start buttons that also signal 'running' state.
|
1NO+1NC
|
|
Cutout Diameter
The hole size you drill in your panel to mount this button. 22mm is the most common industrial standard worldwide.
|
22mm
|
|
Head diameter
|
40mm
|
|
IP Rating
IP65: Dust-tight and protected against low-pressure water jets. Suitable for indoor industrial and light washdown.
|
IP65
|
|
Material
The bezel/body material. Metal bezels are more durable in harsh environments. Plastic is lighter and cheaper.
|
Plastic
|
|
Mounting Type
How the button attaches to the panel. Panel mount is standard — installs through a cutout from the front.
|
Panel
|
|
Max Operating Temp
Highest temperature the button is rated to operate in.
|
55°C
|
|
Min Operating Temp
Lowest temperature the button is rated to operate in.
|
-10°C
|
|
Reset type
|
Twist Release
|
Compatible Alternatives
These products are functionally equivalent cross-references from other manufacturers.
Installation Quick Reference
Panel cutout: 22mm. Mount with the yellow backing plate visible (required by EN/ISO 13850).
Wiring: Wire NC contacts in series with the safety relay input channels. Use dual-channel wiring for SIL 3 / PLe applications. Never wire directly to a motor contactor.
Testing: Press the e-stop and verify the machine stops within the required time. Test the reset mechanism. Repeat monthly per EN/ISO 13850.
Wiring Diagram
Troubleshooting
E-stop won't reset (twist/pull doesn't release)
Check for debris in the mechanism. For twist-release: turn clockwise 45-90 degrees. For push-pull: pull straight out firmly. If the mechanism is stuck, the internal latch may be damaged — replace the entire head assembly.
Machine doesn't stop when e-stop is pressed
Critical safety issue. Immediately lock out the machine. Check wiring — NC contacts must be in series with the safety relay. Verify the safety relay is functioning. A broken wire in an NC circuit should cause a stop, so check for a wiring bypass.
Safety relay faults after e-stop reset
The safety relay detects a cross-fault between the two monitoring channels. Check that both NC contacts on the e-stop are switching simultaneously. One contact may be welded closed — replace the contact block.
