OBSF-30-B
ActiveOBSF-30 Blue 30mm Snap-in
Sanwa OBSF-30 blue arcade button.
Common Applications
Dark blue (dark hai) is the most popular single color for fight stick builds. Clean look, matches most artwork.
Specifications
|
Actuation Force
The force needed to press the button. Lower = more sensitive. Sanwa ~65g (light), Seimitsu ~85g (medium), Happ ~130g (heavy).
|
65g
|
|
Color
Button/actuator color. Green = start/go, Red = stop/emergency, Yellow = caution, Blue = reset (per IEC 60204-1).
|
Blue
|
|
Diameter
|
30mm
|
|
Mechanical Life
How many press cycles before mechanical failure. Higher is better — 10M cycles at 100 presses/day = 274 years.
|
5,000,000 cycles
|
|
Microswitch Type
The internal switch mechanism. Built-in = sealed unit. Cherry D44X = replaceable, clicky. Omron = quieter, longer life.
|
Built-in
|
|
Mounting Type
How the button attaches to the panel. Panel mount is standard — installs through a cutout from the front.
|
Snap-in
|
|
Travel Distance
How far the button moves when pressed. Shorter = faster response. Sanwa 0.85mm is extremely short for competitive gaming.
|
0.85mm
|
Installation Quick Reference
Mounting: Snap-in buttons push into a 30mm hole from the top of the panel. Screw-in buttons thread from below and secure with a nut. Use 2-3mm acrylic, wood, or metal panel.
Wiring: Connect the microswitch terminals to your encoder or PCB. Common ground shared across all buttons. Quick-disconnect (0.110") terminals are standard on Japanese buttons.
Dimensions
Troubleshooting
Not responding to input
Check wiring continuity with a multimeter. Verify the contact block is properly seated. Inspect terminals for loose connections.
Where to Buy
Price range
$23.83 — $39.35
across 2 distributors
Quick Specs
- Actuation Force
- 65g
- Color
- Blue
- Diameter
- 30mm
- Mechanical Life
- 5,000,000 cycles
- Microswitch Type
- Built-in
